Model |
CVL-10+D** |
AVL-1.5 |
Active medium |
Vapor of copper + dye |
Vapor of gold |
Wavelengths |
510.6 nm; 578.2 nm
630-670 nm |
627.8 nm |
Average power, W |
10 |
2 |
1.5 |
Divergence (flat cavity), mrad |
3 |
7 |
3 |
Divergence (telescopic resonator), mrad |
|
|
0.5 |
Beam diameter, mm |
14 |
2 |
14 |
Power consumption |
3 |
3 |
The pulse repetition rate - 8 - 16 kHz
Pulse duration - 20 ns
Cooling - air
Metal vapor lasers have a higher average power in the visible spectrum, giant gain medium, high frequency of pulses, their low duration, high cross-section uniformity of the radiation . A unique combination of energy, spatial and temporal parameters of these lasers can be used in many branches of science, technology and medicine. |
